Corner cutting
Face milling
Helical interpolation
Ramp immersion
Henter tekniske filer …
Kategorier:System DAHM82
Henter matchende værktøj…
Internal cooling| Cutting diameter (Ds) | 40 |
|---|---|
| Key range (SW) | 24 |
| Length from stop (l2) | 35 |
| Maximum stepover (ap) (ap) | 1 |
| Number of revolutions maximum (nmax) | 14500 |
| Number of teeth (Z) | 5 |
| Screw thread (d2) | M16 |
| Total milling length with insert (h) | 58 |
| number-of-teeth | 5 |
