Parting-off
Slotting
Number of teeth Z6
Internal coolingHenter tekniske filer …
Kategorier:System M310 (SAP)
Henter matchende værktøj…
| Cutting diameter (Ds) | 50 |
|---|---|
| Key range (SW) | 15 |
| Left hand indexable insert (linke WSP) | 3x LS310.4023... |
| Length from stop (l2) | 14 |
| Maximum milling depth (tmax) | 15 |
| Neck diameter on stop (d4) | 18 |
| Number of teeth (Z) | 6 |
| Right hand indexable insert (rechte WSP) | 3x RS310.4023... |
| Screw thread (d2) | M10 |
| Width of groove (w) | 4 |
| number-of-teeth | 6 |
