Full radius slot
Parting-off
Slotting
Internal groove
Henter tekniske filer …
Kategorier:System M310 IK
Henter matchende værktøj…
| Cutting width maximum (w) | 3 |
|---|---|
| Cutting diameter (Ds) | 80 |
| Diameter facing system for disk cutters (d2) | 22 |
| Diameter of the mandrel (dK) | 33 |
| Left hand indexable insert (linke WSP) | 4x LS310.3017... |
| Maximum milling depth/ depth of groove (w) | 23 |
| Miller length with indexable insert (hmax) | 40 |
| Number of teeth (Z) | 8 |
| Right hand indexable insert (rechte WSP) | 4x RS310.3017... |
| cutting width max met | 3 |
| number-of-teeth | 8 |
