| eclass shortcut | 21-18-20-11 |
| Maximum depth of groove (tmax) | 1 |
| eclass | 21-18-20-11:Wechselplatte (ADR158005) |
| DIN_SSC | HORN-10512595N |
| ISO-SSC | HORN105125$95N$$$$$ |
| Katalog-SSC | 105125 |
| Head size (a) | 4.7 |
| Neck length (l2) | 30 |
| Neck diameter (d) | 3.5 |
| productnr-sap | R105010055H0CHD03 |
| Total length (l5) | 45 |
| Smallest bore diameter (Da min) | 5 |
| Width of groove (w) | 1 |
| Width of blank (b) | 7 |
