| _application | /conversions/RS18P02001D2_PICTO.JPG |
|---|---|
| _icon | geometrie_d.jpg; innen_einstechen.jpg |
| _download | /documents/RS18P02001D2_20210629_024347661.DXF; /documents/RS18P02001D2_20210630_185822734.STP |
| _drawing | /conversions/18PX_20170127_190147463.JPG |
| _main_image | /conversions/RS18P02001D2.JPG |
| Cutting insert height, Cutting insert thickness (s) | 5.3 |
| Corner radius (r) | 0.2 |
| eclass shortcut | 21-18-20-11 |
| Maximum depth of groove (tmax) | 6 |
| eclass | 21-18-20-11:Wechselplatte (ADR158005) |
| DIN_SSC | HORN-18P11084R |
| ISO-SSC | HORN18P110$84R$$$$$ |
| Katalog-SSC | 18P110R |
| Head size (a) | 17.5 |
| productnr-sap | RS18P02001D2TH35 |
| Smallest bore diameter (Da min) | 18 |
| Width of groove (w) | 2 |
| Tooth diameter, head diameter (d) | 11 |
